Description
Camera alignment Use the built-in HD camera to preview the work area and the work-piece on your laptop or phone. Place your design exactly where you want, and get exactly what you expect. Internal water-cooling The closed-loop water cooling system circulates water throughout the machine, keeping the components at the proper temperature at all times. High resolution laser beamo uses a laser that is smaller than the width of a human hair and engraves with 0.05mm layer depth. The 1,000 DPI resolution will amaze you. Autofocus (optional add-on) Focus will be adjusted according to the thickness of the material, enabling beamo to cut deeper in multiple passes. Rotary Attachment (optional add-on) Unlock beamo’s 3D potential and engrave on curved objects like glassware and bottles. The rotary add-on spins the work-piece. This easy-to-install add-on opens up whole new creative dimensions.
SPECIFICATIONS
GENERAL
Dimensions: 24.21″ x 17.52″ x 6.97″ (615 x 445 x 177 mm) Weight: 48.5 lbs (22 kg) Power: AC 110V Touch Panel: 1024 x 600 LCD Camera: HD CMOS I/O: Wi-Fi / Ethernet Camera Preview Area: 11.81″ x 7.68″ (300 x 195 mm) Work Area: 11.81″ x 8.27″ (300 x 210 mm) Work Area Depth: 1.77″ (45 mm) LASER
Spec: 30 W CO2 Laser Cutting Thickness: 0 – 5 mm (varies by material) Moving Speed: 0 ~ 300 mm/s Maximum Material Height: 45 mm
SOFTWARE
Graphic File Types: Vector / Image (monochrome, gray scale) Supported Operating Systems: Windows / macOSX / Linux / Chrome OS File Types: JPG / PNG / SVG / PDF / DXF
